ROCTECH CNC Router 0609

Model: RC0609
Category: CNC Router for Sign Makers
Brand: Roctech®

The video about ROCTECH CNC Router RC0609

  1. The machine body is made of thick welded steel tubes which have gone through strict tempering and stress relief treatment,not easy to deflect.

  2. DSP control system, Italian air cooling spindle.

  3. Furniture: doors, cabinets, tables and chairs.

  4. Customization special machines are acceptable.

Technical Parameter of ROCTECH CNC Router RC0609

Description

Parameter

ModelRC0609
X,Y,Z TravelingX,Y,Z Traveling
TableT-slot table
FrameWelded Structure
X,Y,Z Drive SystemBall Screw
Max Rapid12000mm/min
Max Working Speed8000mm/min
Spindle Power1.5 kw water cooling spindle
Spindle Speed0-24000RPM
Driving SystemStepper motor
Working VoltageAC220V/380V, 50/60Hz, 3Ph
Command LanguageG code
Operating System

DSP System (options: Ncstudio/Mach3)

SoftwareType3,Ucancam,Artcam,Vetric Pro,UG, Visual Mill, Power Mill, Master Cam, Alpha cam
Gross Weight500KG
OptionsServo motors/HSD spindle
