| Parameter | RC2130DH-ATC |
| X,Y,Z Traveling | 2100x3000x200mm |
| Frame | Welded structure |
| Table size | 2100x3000mm |
| Table Surface | Vacuum and T-slot Combined |
| X, Y Structure | Rack and Pinion, Hiwin Linear Rail |
| Z Structure | Hiwin Rail Linear and Ball Screw |
| Spindle Power | 9KW |
| Spindle Speed | 0-24000RPM |
| Working Voltage | AC380V 50/60Hz,3PH |
| Command Language | G Code |
| Operating System | Syntec System |
| X,Y Resolution | <0.03mm |
| Relative Humidity | 30% - 75% |
| Driving System | Yaskawa Servo Motors |
| G.W | 3450KG |
